IoT A+ Server AS -1115S-FWTRT
Арт. AS -1115HS-TNR
Rackmount система на базе AMD EPYC 9004/9005, память DDR5 до 480GB, 2U форм-фактор.
Нашли дешевле?
| Processor - CPU | Single processor(s) AMD EPYC™ 9004/9005 Series Processors (* AMD EPYC™ 9005 Series drop-in support requires board revision 2.x) |
| Processor - Note | Supports up to 500W TDP CPUs * *Air Cooled CPUs with TDP over 360W only supported under specific conditions. Contact a Supermicro representative for details. * This system supports AMD EPYC™ 9004/9005 Series processors up to 400W TDP |
| System Memory - Memory Voltage | 1.1V |
| On-Board Devices - Chipset | System on Chip |
| Input Output - LAN | 1 RJ45 1 GbE Dedicated BMC LAN port |
| Input Output - USB | 2 USB 3.0 ports(rear) 1 USB 3.0 port(front) |
| Input Output - Video | 1 VGA port |
| PC Health Monitoring - Voltage | System temperature, Memory temperature, CPU temperature, 3.3V standby, +5V standby, +5V, +3.3V, +12V, CPU thermal trip support |
| PC Health Monitoring - FAN | Fans with tachometer monitoring Status monitor for speed control Pulse Width Modulated (PWM) fan connectors |
| PC Health Monitoring - Temperature | Monitoring for CPU and chassis environment Thermal Control for fan connectors |
| Chassis - Form Factor | 1U |
| Chassis - Model | CSE-HS119-R1K24P2-A |
| Dimensions and Weight - Height | 1.7" (43 mm) |
| Dimensions and Weight - Width | 17.2" (437 mm) |
| Dimensions and Weight - Depth | 29.4" (747 mm) |
| Dimensions and Weight - Package | 8.1" (H) x 23.8" (W) x 40.6" (D) |
| Dimensions and Weight - Weight | Gross Weight: 51 lbs (23.1 kg) Net Weight: 32 lbs (14.5 kg) |
| Front Panel - Buttons | Power On/Off UID button |
| System Cooling - Fans | 8 counter-rotating 40x40x56mm Fan(s) |
| System BIOS - BIOS Type | AMI 32MB SPI Flash EEPROM |
| System BIOS - BIOS Features | ACPI 6.4 Plug and Play (PnP) SMBIOS 3.5 or later UEFI 2.8 USB Keyboard support |
| Management - Software | SuperCloud Composer® Supermicro Server Manager (SSM) Supermicro Update Manager (SUM) Supermicro SuperDoctor® 5 (SD5) Super Diagnostics Offline (SDO) Supermicro Thin-Agent Service (TAS) OOB Management Package (SFT-OOB-LIC ) SuperServer Automation Assistant (SAA) New! |
| Operating Environment - Environmental Spec | Operating Temperature: 10°C to 35°C (50°F to 95°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing) |
| On-Board Devices - Network Connectivity | Via AIOM View AIOM Options View AOC Options |
| Dimensions and Weight - Available Color | Black front & silver body |
| Drive Bays Storage - M2 | 1 M.2 PCIe 3.0 x4 NVMe slot (M-key 22110(default)/2280) 1 M.2 PCIe 3.0 x2 NVMe slot (M-key 22110(default)/2280) View M.2 Options |
| System Cooling - Air Shroud | 1 Air Shroud |
| GPU - CPU-GPU Interconnect | PCIe 5.0 x16 CPU-to-GPU Interconnect |
| GPU - GPU-GPU Interconnect | PCIe |
| Processor - Core Count | Up to 192C/320T |
| System Memory - Memory | Slot Count: 24 DIMM slots Max Memory (1DPC): Up to 3TB 4800MT/s ECC DDR5 RDIMM (AMD EPYC™ 9004 Series Processor) Max Memory (2DPC): Up to 6TB 4000MT/s ECC DDR5 RDIMM (AMD EPYC™ 9004 Series Processor) Max Memory (1DPC): Up to 3TB 5200MT/s ECC DDR5 RDIMM (AMD EPYC™ 9005 Series Processor) Max Memory (2DPC): Up to 6TB 4400MT/s ECC DDR5 RDIMM (AMD EPYC™ 9005 Series Processor) View Memory Options |
| Management - Power configurations | ACPI Power Management Power-on mode control for AC power loss recovery Power button override mechanism, |
| Front Panel - LED | HDD activity LAN1 activity Power status System information |
| GPU - Max GPU Count | Up to 1 double-width or 2 single-width GPUs |
| Security - Hardware | Trusted Platform Module (TPM) 2.0 Silicon Root of Trust (RoT) – NIST 800-193 Compliant |
| Expansion Slots - PCI-Express PCIe Configuration | Default 1 PCIe 5.0 x16 FHHL slot 2 PCIe 5.0 x16 FHFL slots 1 PCIe 5.0 x16 AIOM slot (OCP 3.0 compatible) View AOC Options |
| Drive Bays Storage - Drive Bays Configuration | Default: Total 8 bays 8 front hot-swap 2.5" NVMe*/SAS*/SATA* drive bays Option A: Total 12 bays 12 front hot-swap 2.5" NVMe*/SAS*/SATA* drive bays (*NVMe/SAS/SATA support may require additional storage controller and/or cables, please see the optional parts list for details) View NVMe Options View Drive Options |
| GPU - Supported GPU | NVIDIA PCIe: H100, RTX 4000 Ada Generation, L40S, L4 View GPU Options |
| Security - Features | Cryptographically Signed Firmware Secure Boot Secure Firmware Updates Automatic Firmware Recovery Supply Chain Security: Remote Attestation Runtime BMC Protections System Lockdown |
| Environmental Recycling - Recycle | Return Server-End of Life Product |
