SuperServer 2028UT-BTNR
Арт. SYS-2028U-TRTP+
Продается и поддерживается только в составе готовой системы
Нашли дешевле?
| Motherboard | Super X10DRU-i+ |
| System Memory - Memory Capacity | 24x 288-pin DDR4 DIMM slots Up to 3TB † ECC 3DS LRDIMM, 768GB ECC RDIMM |
| System Memory - Memory Type | 2400 † /2133/1866/1600MHz ECC DDR4 SDRAM 72-bit 2666/2400 ECC DDR4 NVDIMM |
| System Memory - DIMM Sizes | RDIMM: 32GB, 16GB, 8GB, 4GB LRDIMM: 64GB, 32GB 3DS LRDIMM: 128GB NVDIMM: 16GB |
| System Memory - Memory Voltage | 1.2 V |
| System Memory - Error Detection | Corrects single-bit errors |
| On-Board Devices - Chipset | Intel® C612 chipset |
| On-Board Devices - SATA | SATA3 (6Gbps) with RAID 0, 1, 5, 10 |
| On-Board Devices - IPMI | Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support ASPEED AST2400 BMC |
| Input Output - SATA | 10x SATA3 (6Gbps) ports |
| Input Output - LAN | 2x 10G SFP+ ports 1x RJ45 Dedicated IPMI LAN port |
| Input Output - USB | 5x USB 3.0 ports (2 rear, 2 onboard header, 1 Type A) |
| Input Output - Video | 1x VGA Connector |
| Input Output - Serial Port Header | 1x Serial header |
| PC Health Monitoring - Voltage | Monitors for CPU Cores, +1.8V, +3.3V, +5V, +12V, +3.3V Standby, +5V Standby, VBAT, Memory Voltages. 5+1 Phase-switching voltage regulator |
| PC Health Monitoring - FAN | 8x 4-pin fan headers Status monitor for speed control Pulse Width Modulated (PWM) fan connectors |
| PC Health Monitoring - Temperature | Support to monitor Supermicro AOC temperatures from IPMI or SD 5 Monitoring for CPU and chassis environment CPU thermal trip support Thermal Control for 8x Fan Connectors Thermal Monitor 2 (TM2) support PECI |
| PC Health Monitoring - LED | Memory DIMM ECC error LEDs CPU / System Overheat LED Suspend static indicator LED UID/Remote UID |
| PC Health Monitoring - Other Features | 4x 8-pin GPU power connectors Chassis intrusion detection Chassis intrusion header SDDC Support RoHS |
| Chassis - Form Factor | 2U Rackmount |
| Chassis - Model | CSE-219UAC-R1K02 |
| Dimensions and Weight - Height | 3.5" (89mm) |
| Dimensions and Weight - Width | 17.2" (437mm) |
| Dimensions and Weight - Depth | 27.76" (705.3mm) |
| Dimensions and Weight - Weight | Net Weight: 36 lbs (16.4 kg) Gross Weight: 72 lbs (32.7 kg) |
| Dimensions and Weight - Available Colors | Black |
| Front Panel - Buttons | Power On/Off button System Reset button UID button |
| Front Panel - LEDs | Power status LED HDD activity LED 2x Network activity LEDs System information (overheat/UID) LED |
| Expansion Slots - PCI-Express | 1x PCI-E 3.0 x16 slot (FH, 10.5" L) 7x PCI-E 3.0 x8 slots (5x FH, 10.5" L, 1x LP, 1x Internal LP) (Both CPUs need to be installed for full access to PCI-E slots and onboard controllers. See manual block diagram and AOC Support for details.) |
| Drive Bays - Hot-swap | 24x Hot-swap 2.5" Drive Bays: 10x SATA3 ports by default Optional drive support: 24x SAS3 Note: optional storage card is required to support more than 10 drives. |
| Backplane | 2U SAS3 backplane |
| System Cooling - Fans | 4x 8cm heavy duty PWM fans |
| Power Supply | 1000W Redundant Power Supplies with PMBus |
| Power Supply - 12V | Max: 66.7A / Min: 0A (100-127Vac) Max: 83A / Min: 0A (200-240Vac) Max: 83A / Min: 0A (200-240Vdc) |
| Power Supply - Certification | Titanium Level [ Test Report ] |
| System BIOS - BIOS Type | 128Mb SPI Flash EEPROM with AMI BIOS |
| Operating Environment Compliance - RoHS | RoHS Compliant |
| Operating Environment Compliance - Environmental Spec | Operating Temperature: 10°C to 35°C (50°F to 95°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing) |
| ProcessorCache - CPU | Intel® Xeon® processor E5-2600 v4 † / v3 family (up to 160W TDP) * Dual Socket R3 (LGA 2011) |
| ProcessorCache - Note | * Please contact Supermicro Technical Support for additional information about frequency optimized CPUs and specialized system optimization. |
| Input Output - SAS | 24x SAS3 ports support via optional Add-on Cards |
| System BIOS - BIOS Features | Plug and Play (PnP) APM 1.2 PCI 2.3 ACPI 1.0 / 2.0 / 3.0 / 4.0 USB Keyboard support SMBIOS 2.7.1 UEFI 2.3.1 |
| Management - Software | SuperDoctor® 5 Intel® Node Manager 3.0 Watch Dog NMI SUM and SSM Optional IPMI 1.5 / 2.0 |
| Management - Power Configurations | ACPI Power Management Power-on mode for AC power recovery |
| Input Output - DOM | 2x Super DOM (Disk on Module) ports |
| On-Board Devices - Graphics | ASPEED AST2400 BMC |
| On-Board Devices - Network Connectivity | 2x 10G SFP+ ports via AOC-2UR68-i2XS Intel® 82599ES 10G SFP+ 1x Realtek RTL8211E PHY (dedicated IPMI) |
| Power Supply - Total Output Power | 800W: 100 – 127Vac 1000W: 200 – 240Vac 1000W: 200 – 240Vdc (for CCC only) |
| Power Supply - DimensionW x H x L | 73.5 x 40 x 203 mm |
| Power Supply - Input | 100-127Vac / 9.8 - 7A / 50-60Hz 200-240Vac / 7 - 5A / 50-60Hz 200-240Vdc / 7 - 5A (for CCC only) |
| Power Supply - 12Vsb | Max: 2.1A / Min: 0A |
| Power Supply - Output Type | 25 Pairs Gold Finger Connector |
| ProcessorCache - Cores Cache | Up to 22 Cores † / Up to 55MB † Cache |
| ProcessorCache - System Bus | QPI up to 9.6 GT/s |
| Product SKUs - SYS-2028U-TRTP | SuperServer 2028U-TRTP+ ( Black ) |
