SuperServer 6018U-TRT
Арт. SYS-6018U-TR4+
Продается и поддерживается только в составе готовой системы
Нашли дешевле?
| Motherboard | Super X10DRU-i+ |
| System Memory - Memory Capacity | 24x 288-pin DDR4 DIMM slots Up to 3TB † ECC 3DS LRDIMM, 1.5TB ECC RDIMM/LRDIMM |
| System Memory - Memory Type | 2400 † /2133/1866/1600MHz ECC DDR4 SDRAM 72-bit 2666/2400 ECC DDR4 NVDIMM |
| System Memory - DIMM Sizes | RDIMM: 64GB, 32GB, 16GB, 8GB, 4GB LRDIMM: 64GB, 32GB 3DS LRDIMM: 128GB NVDIMM: 16GB |
| System Memory - Memory Voltage | 1.2 V |
| System Memory - Error Detection | Corrects single-bit errors |
| On-Board Devices - Chipset | Intel® C612 chipset |
| On-Board Devices - SATA | SATA3 (6Gbps) with RAID 0, 1, 5, 10 |
| On-Board Devices - IPMI | Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support ASPEED AST2400 BMC |
| Input Output - SATA | 4x SATA3 (6Gbps) ports |
| Input Output - LAN | 4x RJ45 Gigabit Ethernet ports 1x RJ45 Dedicated IPMI LAN port |
| Input Output - USB | 5x USB 3.0 ports (2 rear, 2 onboard header, 1 Type A) |
| Input Output - Video | 1x VGA port |
| PC Health Monitoring - Voltage | Monitors for CPU Cores, +1.8V, +3.3V, +5V, +12V, +3.3V Standby, +5V Standby, VBAT, Memory Voltages. 5+1 Phase-switching voltage regulator |
| PC Health Monitoring - FAN | 8x 4-pin fan headers Status monitor for speed control Pulse Width Modulated (PWM) fan connectors |
| PC Health Monitoring - Temperature | Support to monitor Supermicro AOC temperatures from IPMI or SD 5 Monitoring for CPU and chassis environment CPU thermal trip support Thermal Control for 8x Fan Connectors Thermal Monitor 2 (TM2) support PECI |
| PC Health Monitoring - LED | Memory DIMM ECC error LEDs CPU / System Overheat LED Suspend static indicator LED UID/Remote UID |
| PC Health Monitoring - Other Features | 4x 8-pin GPU power connectors Chassis intrusion detection Chassis intrusion header SDDC Support RoHS |
| Chassis - Form Factor | 1U Rackmount |
| Chassis - Model | CSE-819UTQ-R751-T |
| Dimensions and Weight - Height | 1.7" (43mm) |
| Dimensions and Weight - Width | 17.2" (437mm) |
| Dimensions and Weight - Depth | 29.7" (754mm) |
| Dimensions and Weight - Weight | Net Weight: 26 lbs (11.8 kg) Gross Weight: 41 lbs (18.6 kg) |
| Front Panel - Buttons | Power On/Off button System Reset button |
| Front Panel - LEDs | Power LED Hard drive activity LED 2x Network activity LEDs System Overheat LED / Fan fail LED / UID LED |
| Expansion Slots - PCI-Express | 2x PCI-E 3.0 x16 slots (Full-height, 10.5" L) 2x PCI-E 3.0 x8 slots (Low-profile, 1 internal) (Both CPUs need to be installed for full access to PCI-E slots and onboard controllers. See manual block diagram and AOC Support for details.) |
| Drive Bays - Hot-swap | 4x 3.5" Hot-swap drive bays |
| System Cooling - Fans | 4x heavy duty fans with optimal fan speed control 4x additional fans optional |
| Power Supply | 750W Redundant AC-DC Power Supplies, +12V/+12Vsb output |
| Power Supply - 12V | Max: 62.5A & Min: 0A (100Vac-127Vac) Max: 62.5A & Min: 0A (200Vac-240Vac) |
| Power Supply - Certification | Platinum Level [ Test Report ] |
| System BIOS - BIOS Type | 128Mb SPI Flash EEPROM with AMI BIOS |
| Operating Environment Compliance - RoHS | RoHS Compliant |
| Operating Environment Compliance - Environmental Spec | Operating Temperature: 5°C to 40°C (41°F to 104°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing) |
| ProcessorCache - CPU | Intel® Xeon® processor E5-2600 v4 † / v3 family (up to 160W TDP) * Dual Socket R3 (LGA 2011) |
| ProcessorCache - Note | * Please contact Supermicro Technical Support for additional information about frequency optimized CPUs and specialized system optimization. |
| System BIOS - BIOS Features | Plug and Play (PnP) APM 1.2 PCI 2.3 ACPI 1.0 / 2.0 / 3.0 / 4.0 USB Keyboard support SMBIOS 2.7.1 UEFI 2.3.1 |
| Management - Software | SuperDoctor® 5 Intel® Node Manager 3.0 Watch Dog NMI SUM and SSM Optional IPMI 1.5 / 2.0 |
| Management - Power Configurations | ACPI Power Management Power-on mode for AC power recovery |
| Power Supply - AC Input | 100-127Vac, 50-60Hz 200-240Vac, 50-60Hz |
| Input Output - DOM | 2x SATA DOM (Disk on Module) support with embedded power |
| On-Board Devices - Graphics | ASPEED AST2400 BMC |
| On-Board Devices - Network Connectivity | 4x Gigabit Ethernet ports via AOC-UR-i4G Intel® i350 Gigabit Ethernet Controller 1x Realtek RTL8211E PHY (dedicated IPMI) |
| Input Output - Serial Port | 1x Serial header |
| Dimensions and Weight - Available Color | Black |
| System Cooling - Air Shroud | 1x Air Shroud |
| Power Supply - 12V SB | Max: 2.1A Min: 0A |
| ProcessorCache - Cores Cache | Up to 22 Cores † / Up to 55MB † Cache |
| ProcessorCache - System Bus | QPI up to 9.6 GT/s |
| Product SKUs - SYS-6018U-TR4 | SuperServer 6018U-TR4+ ( Black ) |
