SuperServer F618R2-RC0PT+
Арт. SYS-F618R2-R72PT+
Нашли дешевле?
| Motherboard | Super X10DRFR-NT; Super X10DRFR-NT; Super X10DRFR-NT; Super X10DRFR-NT |
| System Memory - Memory Capacity | 16x 288-pin DDR4 DIMM slots Up to 2TB † ECC 3DS LRDIMM, 1TB ECC RDIMM |
| System Memory - Memory Type | 2400 † /2133/1866/1600MHz ECC DDR4 SDRAM 72-bit |
| System Memory - DIMM Sizes | RDIMM: 64GB, 32GB, 16GB, 8GB, 4GB LRDIMM: 64GB, 32GB 3DS LRDIMM: 128GB |
| System Memory - Memory Voltage | 1.2 V |
| System Memory - Error Detection | Corrects single-bit errors |
| On-Board Devices - Chipset | Intel® C612 chipset |
| On-Board Devices - SATA | SATA3 (6Gbps) with RAID 0, 1, 5, 10 |
| On-Board Devices - IPMI | Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support ASPEED AST2400 BMC |
| On-Board Devices - Network Controllers | Intel® X540 Dual Port 10GBase-T Virtual Machine Device Queues reduce I/O overhead Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output 1x Realtek RTL8201N PHY (dedicated IPMI) |
| Chassis - Form Factor | 4U Rackmount |
| Chassis - Model | CSE-F418BC-R1K62BP |
| Dimensions and Weight - Height | 6.96" (177mm) |
| Dimensions and Weight - Width | 17.63" (448mm) |
| Dimensions and Weight - Depth | 29" (737mm) |
| Dimensions and Weight - Package | 28.3" (W) x 15.0" (H) x 42.4" (D) |
| Dimensions and Weight - Weight | Net Weight: 150 lbs (68.04 kg) Gross Weight: 200 lbs (90.71 kg) |
| Dimensions and Weight - Available Colors | Black |
| Front Panel - Buttons | Power On/Off button UID button |
| Front Panel - LEDs | Power status LED Hard drive activity LED 2x Network activity LEDs Information LED (UID, Fan failure, Overheat) |
| Backplane | 1x SAS/SATA backplane; 1x SAS/SATA backplane; 1x SAS/SATA backplane; 1x SAS/SATA backplane |
| Power Supply | 1620W high-efficiency redundant power supply w/ PMBus; 1620W high-efficiency redundant power supply w/ PMBus; 1620W high-efficiency redundant power supply w/ PMBus; 1620W high-efficiency redundant power supply w/ PMBus |
| Power Supply - Certification | Platinum Certified [ Test Report ] |
| System BIOS - BIOS Type | 128Mb SPI Flash EEPROM with AMI BIOS |
| Operating Environment Compliance - RoHS | RoHS Compliant |
| Operating Environment Compliance - Environmental Spec | Operating Temperature: 10°C to 35°C (50°F to 95°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing) |
| Parts List - Items Included | Part Number; Description; Motherboard / Chassis; MBD-X10DRFR-NT CSE-F418BC-R1K62BP; Super X10DRFR-NT Motherboard 4U Chassis; Backplane; BPN-ADP-F418LS; Power Distribution Board for X10DRFR,RoHS/REACH,PBF; Backplane; BPN-ADP-S2208L-H8IR; BPN-ADP-S2208L-H8IR-O-P; SAS AOC for FAT TWIN; Backplane; BPN-SAS-F418-B6; 6-port Fat Twin 6Gbps hot swappable HDD backplane (W/O SGPIO), support up to 6x 2.5-inch SAS/SATA HDD; Cable 1; CBL-0118L-03; MINI SAS-4 SATA,INT,23CM,25.5CM SB,30AWG; Cable 2; CBL-0157L-02; CBL,SGPIO,2X4F TO 2X4F,P2.54,RIBBON IN RND TUBE,27CM,28AWG; Cable 3; CBL-0226L; SATA,INT,ROUND,ST-RA,43CM,26AWG; Cable 4; CBL-0486L; 2x2 to 2x2 15cm power cable HF. 18AWG; Cable 5; CBL-OTHR-0022L; 20 to 20 pin cable for BPN-ADP-F418LS,7.5cm, 28AWG,RoHS/REACH,PBF; Cable 6; CBL-PWCD-0900; PWCD,US/EU/Canada/China/Australia,IEC60320 C14 TO C13,4FT,17AWG; Manual; MNL-1651-QRG; Quick Reference Guide for SYS-618R2-RTPT+/R72PT+,HF,RoHS/REACH; Riser Card; RSC-R1UF-E16R; RSC-R1UF-E16R; Heatsink / Retention; SNK-P0047PSM; 1U Passive Front CPU Heat Sink w/ a Middle Air Channel for X9, X10 2U Twin^2+ and Twin Pro^2 Series Servers; Heatsink / Retention; SNK-P0057P; 1U High Performance Passive CPU Heat Sink for X9, X10 Systems Equipped w/ a Square ILM MB; * Power Supply; PWS-1K62P-1R; 1620W REDUNDANT POWER MODULE; * Backplane; BPN-PDB-F418; Fat Twin Mid-plane; support 2x PS; 4x MB hot-swap & over-current connection; Front panel connection and 4X PWM fan control; * Rail Set; MCP-290-41803-0N; Fat twin F418 / F424 Static Rail set support 28-33.5 inch depth rail,RoHS/REACH,PBF; Part Number; Description; Motherboard / Chassis; MBD-X10DRFR-NT CSE-F418BC-R1K62BP; Super X10DRFR-NT Motherboard 4U Chassis; Backplane; BPN-ADP-F418LS; Power Distribution Board for X10DRFR,RoHS/REACH,PBF; Backplane; BPN-ADP-S2208L-H8IR; BPN-ADP-S2208L-H8IR-O-P; SAS AOC for FAT TWIN; Backplane; BPN-SAS-F418-B6; 6-port Fat Twin 6Gbps hot swappable HDD backplane (W/O SGPIO), support up to 6x 2.5-inch SAS/SATA HDD; Cable 1; CBL-0118L-03; MINI SAS-4 SATA,INT,23CM,25.5CM SB,30AWG; Cable 2; CBL-0157L-02; CBL,SGPIO,2X4F TO 2X4F,P2.54,RIBBON IN RND TUBE,27CM,28AWG; Cable 3; CBL-0226L; SATA,INT,ROUND,ST-RA,43CM,26AWG; Cable 4; CBL-0486L; 2x2 to 2x2 15cm power cable HF. 18AWG; Cable 5; CBL-OTHR-0022L; 20 to 20 pin cable for BPN-ADP-F418LS,7.5cm, 28AWG,RoHS/REACH,PBF; Cable 6; CBL-PWCD-0900; PWCD,US/EU/Canada/China/Australia,IEC60320 C14 TO C13,4FT,17AWG; Manual; MNL-1651-QRG; Quick Reference Guide for SYS-618R2-RTPT+/R72PT+,HF,RoHS/REACH; Riser Card; RSC-R1UF-E16R; RSC-R1UF-E16R; Heatsink / Retention; SNK-P0047PSM; 1U Passive Front CPU Heat Sink w/ a Middle Air Channel for X9, X10 2U Twin^2+ and Twin Pro^2 Series Servers; Heatsink / Retention; SNK-P0057P; 1U High Performance Passive CPU Heat Sink for X9, X10 Systems Equipped w/ a Square ILM MB; * Power Supply; PWS-1K62P-1R; 1620W REDUNDANT POWER MODULE; * Backplane; BPN-PDB-F418; Fat Twin Mid-plane; support 2x PS; 4x MB hot-swap & over-current connection; Front panel connection and 4X PWM fan control; * Rail Set; MCP-290-41803-0N; Fat twin F418 / F424 Static Rail set support 28-33.5 inch depth rail,RoHS/REACH,PBF; Part Number; Description; Motherboard / Chassis; MBD-X10DRFR-NT CSE-F418BC-R1K62BP; Super X10DRFR-NT Motherboard 4U Chassis; Backplane; BPN-ADP-F418LS; Power Distribution Board for X10DRFR,RoHS/REACH,PBF; Backplane; BPN-ADP-S2208L-H8IR; BPN-ADP-S2208L-H8IR-O-P; SAS AOC for FAT TWIN; Backplane; BPN-SAS-F418-B6; 6-port Fat Twin 6Gbps hot swappable HDD backplane (W/O SGPIO), support up to 6x 2.5-inch SAS/SATA HDD; Cable 1; CBL-0118L-03; MINI SAS-4 SATA,INT,23CM,25.5CM SB,30AWG; Cable 2; CBL-0157L-02; CBL,SGPIO,2X4F TO 2X4F,P2.54,RIBBON IN RND TUBE,27CM,28AWG; Cable 3; CBL-0226L; SATA,INT,ROUND,ST-RA,43CM,26AWG; Cable 4; CBL-0486L; 2x2 to 2x2 15cm power cable HF. 18AWG; Cable 5; CBL-OTHR-0022L; 20 to 20 pin cable for BPN-ADP-F418LS,7.5cm, 28AWG,RoHS/REACH,PBF; Cable 6; CBL-PWCD-0900; PWCD,US/EU/Canada/China/Australia,IEC60320 C14 TO C13,4FT,17AWG; Manual; MNL-1651-QRG; Quick Reference Guide for SYS-618R2-RTPT+/R72PT+,HF,RoHS/REACH; Riser Card; RSC-R1UF-E16R; RSC-R1UF-E16R; Heatsink / Retention; SNK-P0047PSM; 1U Passive Front CPU Heat Sink w/ a Middle Air Channel for X9, X10 2U Twin^2+ and Twin Pro^2 Series Servers; Heatsink / Retention; SNK-P0057P; 1U High Performance Passive CPU Heat Sink for X9, X10 Systems Equipped w/ a Square ILM MB; * Power Supply; PWS-1K62P-1R; 1620W REDUNDANT POWER MODULE; * Backplane; BPN-PDB-F418; Fat Twin Mid-plane; support 2x PS; 4x MB hot-swap & over-current connection; Front panel connection and 4X PWM fan control; * Rail Set; MCP-290-41803-0N; Fat twin F418 / F424 Static Rail set support 28-33.5 inch depth rail,RoHS/REACH,PBF; Part Number; Description; Motherboard / Chassis; MBD-X10DRFR-NT CSE-F418BC-R1K62BP; Super X10DRFR-NT Motherboard 4U Chassis; Backplane; BPN-ADP-F418LS; Power Distribution Board for X10DRFR,RoHS/REACH,PBF; Backplane; BPN-ADP-S2208L-H8IR; BPN-ADP-S2208L-H8IR-O-P; SAS AOC for FAT TWIN; Backplane; BPN-SAS-F418-B6; 6-port Fat Twin 6Gbps hot swappable HDD backplane (W/O SGPIO), support up to 6x 2.5-inch SAS/SATA HDD; Cable 1; CBL-0118L-03; MINI SAS-4 SATA,INT,23CM,25.5CM SB,30AWG; Cable 2; CBL-0157L-02; CBL,SGPIO,2X4F TO 2X4F,P2.54,RIBBON IN RND TUBE,27CM,28AWG; Cable 3; CBL-0226L; SATA,INT,ROUND,ST-RA,43CM,26AWG; Cable 4; CBL-0486L; 2x2 to 2x2 15cm power cable HF. 18AWG; Cable 5; CBL-OTHR-0022L; 20 to 20 pin cable for BPN-ADP-F418LS,7.5cm, 28AWG,RoHS/REACH,PBF; Cable 6; CBL-PWCD-0900; PWCD,US/EU/Canada/China/Australia,IEC60320 C14 TO C13,4FT,17AWG; Manual; MNL-1651-QRG; Quick Reference Guide for SYS-618R2-RTPT+/R72PT+,HF,RoHS/REACH; Riser Card; RSC-R1UF-E16R; RSC-R1UF-E16R; Heatsink / Retention; SNK-P0047PSM; 1U Passive Front CPU Heat Sink w/ a Middle Air Channel for X9, X10 2U Twin^2+ and Twin Pro^2 Series Servers; Heatsink / Retention; SNK-P0057P; 1U High Performance Passive CPU Heat Sink for X9, X10 Systems Equipped w/ a Square ILM MB; * Power Supply; PWS-1K62P-1R; 1620W REDUNDANT POWER MODULE; * Backplane; BPN-PDB-F418; Fat Twin Mid-plane; support 2x PS; 4x MB hot-swap & over-current connection; Front panel connection and 4X PWM fan control; * Rail Set; MCP-290-41803-0N; Fat twin F418 / F424 Static Rail set support 28-33.5 inch depth rail,RoHS/REACH,PBF |
| Optional Parts List | Part Number; Description; Optional kit; MCP-450-00001-0N BTR-0022L-LSI00279; Broadcom iBBU09 extension kit (to installed at 2.5" HDD location) LSI00279 IBBU09 BATTERY BKUP FOR SAS2208; Software; SFT-OOB-LIC •; OOB Management Package (per node license); Software; SFT-DCMS-Single; DataCenter Management Package (per node license); Part Number; Description; Optional kit; MCP-450-00001-0N BTR-0022L-LSI00279; Broadcom iBBU09 extension kit (to installed at 2.5" HDD location) LSI00279 IBBU09 BATTERY BKUP FOR SAS2208; Software; SFT-OOB-LIC •; OOB Management Package (per node license); Software; SFT-DCMS-Single; DataCenter Management Package (per node license); Part Number; Description; Optional kit; MCP-450-00001-0N BTR-0022L-LSI00279; Broadcom iBBU09 extension kit (to installed at 2.5" HDD location) LSI00279 IBBU09 BATTERY BKUP FOR SAS2208; Software; SFT-OOB-LIC •; OOB Management Package (per node license); Software; SFT-DCMS-Single; DataCenter Management Package (per node license); Part Number; Description; Optional kit; MCP-450-00001-0N BTR-0022L-LSI00279; Broadcom iBBU09 extension kit (to installed at 2.5" HDD location) LSI00279 IBBU09 BATTERY BKUP FOR SAS2208; Software; SFT-OOB-LIC •; OOB Management Package (per node license); Software; SFT-DCMS-Single; DataCenter Management Package (per node license) |
| ProcessorCache - CPU | Intel® Xeon® processor E5-2600 v4 † / v3 family (up to 145W TDP) * Dual Socket R3 (LGA 2011) |
| ProcessorCache - Note | * Please contact Supermicro Technical Support for additional information about frequency optimized CPUs and specialized system optimization. |
| On-Board Devices - SAS | SAS2 via Broadcom 2208 (1GB cache) HW RAID 0, 1, 5, 6, 10, 50 support |
| System BIOS - BIOS Features | Plug and Play (PnP) APM 1.2 PCI 2.2 ACPI 1.0 / 2.0 USB Keyboard support SMBIOS 2.3 UEFI |
| Management - Software | SuperDoctor® 5 Watch Dog NMI IPMI 2.0 SUM and SSM |
| Management - Power Configurations | ACPI / APM Power Management Power-on mode for AC power recovery |
| Power Supply - AC Input | 1000W Output @ 100-120V, 12-10A, 50-60Hz 1200W Output @ 120-140V, 12-10A, 50-60Hz 1620W Output @ 180-240V, 10.5-8A, 50-60Hz |
| On-Board Devices - Graphics | ASPEED AST2400 BMC |
| Expansion Slots per node - PCI-Express | 1x PCI-E 3.0 x16 Low-profile 1x PCI-E 3.0 x8 (Micro LP) MicroLP Adapter Matrix (Networking options) |
| Input Output per node - LAN | 2x RJ45 10GBase-T ports 1x RJ45 Dedicated IPMI LAN port |
| Power Supply - DC Output | 1000W: +12V/84A; +5Vsb/4A 1200W: +12V/100A; +5Vsb/4A 1620W: +12V/150A; +5Vsb/4A |
| Input Output per node - USB | 2x USB 3.0 ports |
| Input Output per node - VGA | 1x VGA port |
| Drive Bays per node - Hot-swap | 6x 2.5" Hot-swap SAS2/SATA3 HDD trays |
| Drive Bays per node - M2 | M.2 Interface: PCI-E 3.0 x4 M.2 Form Factor: 2260, 2280, 22110 M.2 Key: M-Key |
| System Cooling per node - Fans | 3x 4cm 14k RPM middle fans |
| Input Output per node - SAS | 8x SAS2 (6Gbps) ports |
| ProcessorCache - Cores Cache | Up to 22 Cores † / Up to 55MB † Cache |
| ProcessorCache - System Bus | QPI up to 9.6 GT/s |
| Input Output per node - Serial ATA | 10x SATA3 (6Gbps) ports |
| Product SKUs - SYS-F618R2-R72PT | SuperServer F618R2-R72PT+ ( Black ) |
