SuperServer F618R2-RTN+
Арт. SYS-F618R2-RC1PT+
Нашли дешевле?
| Motherboard | Super X10DRFR-NT; Super X10DRFR-NT; Super X10DRFR-NT; Super X10DRFR-NT |
| System Memory - Memory Capacity | 16x 288-pin DDR4 DIMM slots Up to 2TB † ECC 3DS LRDIMM, 1TB ECC RDIMM |
| System Memory - Memory Type | 2400 † /2133/1866/1600MHz ECC DDR4 SDRAM 72-bit |
| System Memory - DIMM Sizes | RDIMM: 64GB, 32GB, 16GB, 8GB, 4GB LRDIMM: 64GB, 32GB 3DS LRDIMM: 128GB |
| System Memory - Memory Voltage | 1.2 V |
| System Memory - Error Detection | Corrects single-bit errors |
| On-Board Devices - Chipset | Intel® C612 chipset |
| On-Board Devices - SATA | SATA3 (6Gbps) with RAID 0, 1, 5, 10 |
| On-Board Devices - IPMI | Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support ASPEED AST2400 BMC |
| On-Board Devices - Network Controllers | Intel® X540 Dual Port 10GBase-T Virtual Machine Device Queues reduce I/O overhead Supports 10GBASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output 1x Realtek RTL8201N PHY (dedicated IPMI) |
| Chassis - Form Factor | 4U Rackmount |
| Chassis - Model | CSE-F418BC-R2K04BP |
| Dimensions and Weight - Height | 6.96" (177mm) |
| Dimensions and Weight - Width | 17.63" (448mm) |
| Dimensions and Weight - Depth | 29" (737mm) |
| Dimensions and Weight - Package | 28.3" (W) x 15.0" (H) x 42.4" (D) |
| Dimensions and Weight - Weight | Net Weight: 150 lbs (68.04 kg) Gross Weight: 200 lbs (90.71 kg) |
| Dimensions and Weight - Available Colors | Black |
| Front Panel - Buttons | Power On/Off button UID button |
| Front Panel - LEDs | Power status LED Hard drive activity LED 2 Network activity LEDs Information LED (UID, Fan failure, Overheat) |
| Backplane | 1x SAS/SATA backplane; 1x SAS/SATA backplane; 1x SAS/SATA backplane; 1x SAS/SATA backplane |
| System BIOS - BIOS Type | 128Mb SPI Flash EEPROM with AMI BIOS |
| Operating Environment Compliance - RoHS | RoHS Compliant |
| Operating Environment Compliance - Environmental Spec | Operating Temperature: 10°C to 35°C (50°F to 95°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing) |
| Parts List - Items Included | Part Number; Description; Motherboard / Chassis; MBD-X10DRFR-NT CSE-F418BC-R2K04BP; Super X10DRFR-NT Motherboard 4U Chassis; Backplane; BPN-ADP-8S3108-1UF; Avago (LSI) 3108 adapter card for X10 FatTwin Rear I/O motherboards. Adapter card includes TFM module port and x8 SAS3 ports via x2 Mini-SAS HD connectors,HF,RoHS/REACH; Backplane; BPN-ADP-F418LS; Power Distribution Board for X10DRFR,RoHS/REACH,PBF; Backplane; BPN-SAS3-F418-B6N2; 6-port Fat Twin SAS3 12Gbps hybrid backplane, support up to 4x 2.5-inch SAS3/SATA3 HDD/SSD and 2x NVMe/SAS3/SATA3 storage devices; Cable 1; CBL-0486L; 2x2 to 2x2 15cm power cable HF. 18AWG; Cable 2; CBL-OTHR-0022L; 20 to 20 pin cable for BPN-ADP-F418LS,7.5cm, 28AWG,RoHS/REACH,PBF; Cable 3; CBL-PWCD-0578; PWCD,US,IEC60320 C14 TO C13,3FT,14AWG; Cable 4; CBL-SAST-0697; MINI SAS HD,12G,INT,6CM,30AWG; Manual; MNL-1761-QRG; Quick Reference Guide for F618R2-RC1+/RC1PT+; Riser Card; RSC-R1UF-E16R; RSC-R1UF-E16R; Heatsink / Retention; SNK-P0047PSM; 1U Passive Front CPU Heat Sink w/ a Middle Air Channel for X9, X10 2U Twin^2+ and Twin Pro^2 Series Servers; Heatsink / Retention; SNK-P0057P; 1U High Performance Passive CPU Heat Sink for X9, X10 Systems Equipped w/ a Square ILM MB; * Power Supply; PWS-2K04A-1R; AC-DC 2000W, Titanium Level, Redundancy, 1U, PMBus 1.2, +12V/+5Vsb, 360x76x40mm,HF,RoHS/REACH; * Backplane; BPN-PDB-F418; Fat Twin Mid-plane; support 2x PS; 4x MB hot-swap & over-current connection; Front panel connection and 4X PWM fan control; * Rail Set; MCP-290-41803-0N; Fat twin F418 / F424 Static Rail set support 28-33.5 inch depth rail,RoHS/REACH,PBF; Part Number; Description; Motherboard / Chassis; MBD-X10DRFR-NT CSE-F418BC-R2K04BP; Super X10DRFR-NT Motherboard 4U Chassis; Backplane; BPN-ADP-8S3108-1UF; Avago (LSI) 3108 adapter card for X10 FatTwin Rear I/O motherboards. Adapter card includes TFM module port and x8 SAS3 ports via x2 Mini-SAS HD connectors,HF,RoHS/REACH; Backplane; BPN-ADP-F418LS; Power Distribution Board for X10DRFR,RoHS/REACH,PBF; Backplane; BPN-SAS3-F418-B6N2; 6-port Fat Twin SAS3 12Gbps hybrid backplane, support up to 4x 2.5-inch SAS3/SATA3 HDD/SSD and 2x NVMe/SAS3/SATA3 storage devices; Cable 1; CBL-0486L; 2x2 to 2x2 15cm power cable HF. 18AWG; Cable 2; CBL-OTHR-0022L; 20 to 20 pin cable for BPN-ADP-F418LS,7.5cm, 28AWG,RoHS/REACH,PBF; Cable 3; CBL-PWCD-0578; PWCD,US,IEC60320 C14 TO C13,3FT,14AWG; Cable 4; CBL-SAST-0697; MINI SAS HD,12G,INT,6CM,30AWG; Manual; MNL-1761-QRG; Quick Reference Guide for F618R2-RC1+/RC1PT+; Riser Card; RSC-R1UF-E16R; RSC-R1UF-E16R; Heatsink / Retention; SNK-P0047PSM; 1U Passive Front CPU Heat Sink w/ a Middle Air Channel for X9, X10 2U Twin^2+ and Twin Pro^2 Series Servers; Heatsink / Retention; SNK-P0057P; 1U High Performance Passive CPU Heat Sink for X9, X10 Systems Equipped w/ a Square ILM MB; * Power Supply; PWS-2K04A-1R; AC-DC 2000W, Titanium Level, Redundancy, 1U, PMBus 1.2, +12V/+5Vsb, 360x76x40mm,HF,RoHS/REACH; * Backplane; BPN-PDB-F418; Fat Twin Mid-plane; support 2x PS; 4x MB hot-swap & over-current connection; Front panel connection and 4X PWM fan control; * Rail Set; MCP-290-41803-0N; Fat twin F418 / F424 Static Rail set support 28-33.5 inch depth rail,RoHS/REACH,PBF; Part Number; Description; Motherboard / Chassis; MBD-X10DRFR-NT CSE-F418BC-R2K04BP; Super X10DRFR-NT Motherboard 4U Chassis; Backplane; BPN-ADP-8S3108-1UF; Avago (LSI) 3108 adapter card for X10 FatTwin Rear I/O motherboards. Adapter card includes TFM module port and x8 SAS3 ports via x2 Mini-SAS HD connectors,HF,RoHS/REACH; Backplane; BPN-ADP-F418LS; Power Distribution Board for X10DRFR,RoHS/REACH,PBF; Backplane; BPN-SAS3-F418-B6N2; 6-port Fat Twin SAS3 12Gbps hybrid backplane, support up to 4x 2.5-inch SAS3/SATA3 HDD/SSD and 2x NVMe/SAS3/SATA3 storage devices; Cable 1; CBL-0486L; 2x2 to 2x2 15cm power cable HF. 18AWG; Cable 2; CBL-OTHR-0022L; 20 to 20 pin cable for BPN-ADP-F418LS,7.5cm, 28AWG,RoHS/REACH,PBF; Cable 3; CBL-PWCD-0578; PWCD,US,IEC60320 C14 TO C13,3FT,14AWG; Cable 4; CBL-SAST-0697; MINI SAS HD,12G,INT,6CM,30AWG; Manual; MNL-1761-QRG; Quick Reference Guide for F618R2-RC1+/RC1PT+; Riser Card; RSC-R1UF-E16R; RSC-R1UF-E16R; Heatsink / Retention; SNK-P0047PSM; 1U Passive Front CPU Heat Sink w/ a Middle Air Channel for X9, X10 2U Twin^2+ and Twin Pro^2 Series Servers; Heatsink / Retention; SNK-P0057P; 1U High Performance Passive CPU Heat Sink for X9, X10 Systems Equipped w/ a Square ILM MB; * Power Supply; PWS-2K04A-1R; AC-DC 2000W, Titanium Level, Redundancy, 1U, PMBus 1.2, +12V/+5Vsb, 360x76x40mm,HF,RoHS/REACH; * Backplane; BPN-PDB-F418; Fat Twin Mid-plane; support 2x PS; 4x MB hot-swap & over-current connection; Front panel connection and 4X PWM fan control; * Rail Set; MCP-290-41803-0N; Fat twin F418 / F424 Static Rail set support 28-33.5 inch depth rail,RoHS/REACH,PBF; Part Number; Description; Motherboard / Chassis; MBD-X10DRFR-NT CSE-F418BC-R2K04BP; Super X10DRFR-NT Motherboard 4U Chassis; Backplane; BPN-ADP-8S3108-1UF; Avago (LSI) 3108 adapter card for X10 FatTwin Rear I/O motherboards. Adapter card includes TFM module port and x8 SAS3 ports via x2 Mini-SAS HD connectors,HF,RoHS/REACH; Backplane; BPN-ADP-F418LS; Power Distribution Board for X10DRFR,RoHS/REACH,PBF; Backplane; BPN-SAS3-F418-B6N2; 6-port Fat Twin SAS3 12Gbps hybrid backplane, support up to 4x 2.5-inch SAS3/SATA3 HDD/SSD and 2x NVMe/SAS3/SATA3 storage devices; Cable 1; CBL-0486L; 2x2 to 2x2 15cm power cable HF. 18AWG; Cable 2; CBL-OTHR-0022L; 20 to 20 pin cable for BPN-ADP-F418LS,7.5cm, 28AWG,RoHS/REACH,PBF; Cable 3; CBL-PWCD-0578; PWCD,US,IEC60320 C14 TO C13,3FT,14AWG; Cable 4; CBL-SAST-0697; MINI SAS HD,12G,INT,6CM,30AWG; Manual; MNL-1761-QRG; Quick Reference Guide for F618R2-RC1+/RC1PT+; Riser Card; RSC-R1UF-E16R; RSC-R1UF-E16R; Heatsink / Retention; SNK-P0047PSM; 1U Passive Front CPU Heat Sink w/ a Middle Air Channel for X9, X10 2U Twin^2+ and Twin Pro^2 Series Servers; Heatsink / Retention; SNK-P0057P; 1U High Performance Passive CPU Heat Sink for X9, X10 Systems Equipped w/ a Square ILM MB; * Power Supply; PWS-2K04A-1R; AC-DC 2000W, Titanium Level, Redundancy, 1U, PMBus 1.2, +12V/+5Vsb, 360x76x40mm,HF,RoHS/REACH; * Backplane; BPN-PDB-F418; Fat Twin Mid-plane; support 2x PS; 4x MB hot-swap & over-current connection; Front panel connection and 4X PWM fan control; * Rail Set; MCP-290-41803-0N; Fat twin F418 / F424 Static Rail set support 28-33.5 inch depth rail,RoHS/REACH,PBF |
| Optional Parts List | Part Number; Description; CacheVault Kit; BTR-CV3108-FT1; 1/node; CacheVault kit for FatTwin Broadcom 3108 card. Includes: TFM, cables, brackets and supercap; NVMe Cable; CBL-SAST-0698; 2/node; 10cm NVMe cable; RA-RA; Software; SFT-OOB-LIC •; OOB Management Package (per node license); Software; SFT-DCMS-Single; DataCenter Management Package (per node license); Part Number; Description; CacheVault Kit; BTR-CV3108-FT1; 1/node; CacheVault kit for FatTwin Broadcom 3108 card. Includes: TFM, cables, brackets and supercap; NVMe Cable; CBL-SAST-0698; 2/node; 10cm NVMe cable; RA-RA; Software; SFT-OOB-LIC •; OOB Management Package (per node license); Software; SFT-DCMS-Single; DataCenter Management Package (per node license); Part Number; Description; CacheVault Kit; BTR-CV3108-FT1; 1/node; CacheVault kit for FatTwin Broadcom 3108 card. Includes: TFM, cables, brackets and supercap; NVMe Cable; CBL-SAST-0698; 2/node; 10cm NVMe cable; RA-RA; Software; SFT-OOB-LIC •; OOB Management Package (per node license); Software; SFT-DCMS-Single; DataCenter Management Package (per node license); Part Number; Description; CacheVault Kit; BTR-CV3108-FT1; 1/node; CacheVault kit for FatTwin Broadcom 3108 card. Includes: TFM, cables, brackets and supercap; NVMe Cable; CBL-SAST-0698; 2/node; 10cm NVMe cable; RA-RA; Software; SFT-OOB-LIC •; OOB Management Package (per node license); Software; SFT-DCMS-Single; DataCenter Management Package (per node license) |
| ProcessorCache - CPU | Intel® Xeon® processor E5-2600 v4 † / v3 family (up to 145W TDP) * Dual Socket R3 (LGA 2011) |
| ProcessorCache - Note | * Please contact Supermicro Technical Support for additional information about frequency optimized CPUs and specialized system optimization. |
| On-Board Devices - SAS | Broadcom 3108 SAS3 (12Gbps) controller; HW RAID 0, 1, 5, 6, 10, 50 |
| System BIOS - BIOS Features | Plug and Play (PnP) APM 1.2 PCI 2.2 ACPI 1.0 / 2.0 USB Keyboard support SMBIOS 2.3 UEFI |
| Management - Software | Intel® Node Manager SuperDoctor® 5 Watch Dog NMI IPMI 2.0 SUM and SSM |
| Management - Power Configurations | ACPI / APM Power Management Power-on mode for AC power recovery |
| On-Board Devices - Graphics | ASPEED AST2400 BMC |
| Expansion Slots per node - PCI-Express | 1 PCI-E 3.0 x16 Low-profile 1 PCI-E 3.0 x8 (Micro LP) MicroLP Adapter Matrix (Networking options) |
| Input Output per node - LAN | 2 RJ45 10GBase-T LAN ports 1 RJ45 Dedicated IPMI LAN port |
| Power Supply 76mm Width | 2000W Redundant Power Supplies with PMBus; 2000W Redundant Power Supplies with PMBus; 2000W Redundant Power Supplies with PMBus; 2000W Redundant Power Supplies with PMBus |
| Power Supply 76mm Width - Total Output Power | 1000W: 100 – 127Vac 1800W: 200 – 220Vac 1980W: 220 – 230Vac 2000W: 230 – 240Vac 2000W: 200 – 240Vdc (UL/cUL only) |
| Power Supply 76mm Width - DimensionW x H x L | 76 x 40 x 336 mm |
| Power Supply 76mm Width - Input | 1000W: 100-127 Vac / 12-9.5 A / 50-60 Hz 1800W: 200-220 Vac / 10-9.5 A / 50-60 Hz 1980W: 220-230 Vac / 10-9.8 A / 50-60 Hz 2000W: 230-240 Vac / 10-9.8 A / 50-60 Hz 2000W: 200-240 Vac / 11.8-9.8 A / 50-60 Hz (UL/cUL only) |
| Power Supply 76mm Width - 12V | Max: 83.3A / Min: 0A (100-127 Vac) Max: 150A / Min: 0A (200-220 Vac) Max: 165A / Min: 0A (220-230 Vac) Max: 166.7A / Min: 0A (230-240 Vac) Max: 166.7A / Min: 0A (200-240 Vac) (UL/cUL only) |
| Power Supply 76mm Width - 5Vsb | Max: 1A / Min: 0A |
| Power Supply 76mm Width - Output Type | 27 Pairs Gold Finger Connector |
| Power Supply 76mm Width - Certification | Titanium Level [ Test Report ] |
| Input Output per node - NVMe | 2 Internal NVMe ports (PCI-E 3.0 x4) Note: NVMe support requires 2 CPUs installed |
| Input Output per node - USB | 2 USB 3.0 ports |
| Input Output per node - VGA | 1 VGA port |
| Drive Bays per node - Hot-swap | 6x 2.5" Hot-swap SAS/SATA drives Optional NVMe support Note: NVMe support requires 2 CPUs installed |
| System Cooling per node - Fans | 3x 4cm 14k RPM middle fans |
| Input Output per node - SAS | 6 SAS3 (12Gbps) ports |
| ProcessorCache - Cores Cache | Up to 22 Cores † / Up to 55MB † Cache |
| ProcessorCache - System Bus | QPI up to 9.6 GT/s |
| Product SKUs - SYS-F618R2-RC1PT | SuperServer F618R2-RC1PT+ ( Black ) |
