SuperServer 1029P-N32
Арт. SYS-1029P-MT
Нашли дешевле?
| Motherboard | Super X11DPL-i; Super X11DPL-i; Super X11DPL-i; Super X11DPL-i |
| Processor - CPU | Dual Socket P (LGA 3647) 2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors ‡ , Dual UPI up to 10.4GT/s Support CPU TDP 70-140W with IVR |
| Processor - Note | ‡ BIOS version 3.2 or above is required to support 2nd Gen Intel® Xeon® Scalable processors (codenamed Cascade Lake-R) |
| System Memory - Memory Capacity | 8 DIMM slots Up to 2TB 3DS ECC DDR4-2933MHz † RDIMM/LRDIMM |
| System Memory - Memory Type | 2933 † /2666/2400/2133MHz ECC DDR4 RDIMM/LRDIMM |
| On-Board Devices - Chipset | Intel® C621 chipset |
| On-Board Devices - SATA | SATA3 (6Gbps); RAID 0, 1, 5, 10 |
| On-Board Devices - IPMI | Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support |
| On-Board Devices - Network Controllers | Marvell 88E1512 PHY Gigabit Ethernet controller Supports 1000BASE-T |
| On-Board Devices - Video | ASPEED AST2500 BMC |
| Input Output - SATA | 8 SATA3 (6Gbps) ports |
| Input Output - LAN | 2 RJ45 Gigabit Ethernet LAN ports 1 RJ45 Dedicated IPMI LAN port |
| Input Output - USB | 2 USB 2.0 ports (rear) |
| Input Output - Video | 1 VGA port |
| Input Output - Serial Port Header | 1 COM port (header) |
| PC Health Monitoring - FAN | Fans with tachometer monitoring Status monitor for speed control Pulse Width Modulated (PWM) fan connectors |
| PC Health Monitoring - Temperature | Monitoring for CPU and chassis environment Thermal Control for fan connectors |
| Chassis - Form Factor | 1U Rackmount |
| Chassis - Model | CSE-113MFAC2-605CB |
| Dimensions and Weight - Height | 1.7" (43mm) |
| Dimensions and Weight - Width | 17.2" (437mm) |
| Dimensions and Weight - Depth | 19.98" (508mm) |
| Dimensions and Weight - Package | 23.4" (W) x 8.5" (H) x 29.7" (L) |
| Dimensions and Weight - Weight | Gross Weight: 29.8 lbs (13.5 kg) |
| Dimensions and Weight - Available Colors | Black |
| Front Panel - Buttons | Power On/Off button System Reset button |
| Front Panel - LEDs | Power status LED HDD activity LED Network activity LEDs Universal Information (UID) LED |
| Expansion Slots - PCI-Express | 1 PCI-E 3.0 x8 (FHHL) slot |
| Drive Bays - Hot-swap | 8 Hot-swap 2.5" SATA3 drive bays |
| Peripheral Drives - Optional | 1 Slim DVD-ROM drive (optional) PCIe/SATA M.2 drive (optional) |
| System Cooling - Fans | 4x 4cm 22.5K RPM middle cooling fans |
| Power Supply | 600W High-Efficiency Power Supply w/PMBus 1.2, I 2 C, PFC, and Digital Switching; 600W High-Efficiency Power Supply w/PMBus 1.2, I 2 C, PFC, and Digital Switching; 600W High-Efficiency Power Supply w/PMBus 1.2, I 2 C, PFC, and Digital Switching; 600W High-Efficiency Power Supply w/PMBus 1.2, I 2 C, PFC, and Digital Switching |
| Power Supply - Certification | Platinum Certified [ Test Report ] |
| System BIOS - BIOS Type | 256Mb SPI Flash EEPROM with AMI BIOS |
| Parts List - Items Included | Part Number; Description; Motherboard / Chassis; MBD-X11DPL-i CSE-113MFAC2-605CB; Super X11DPL-i Motherboard 1U Chassis; Backplane; BPN-SAS3-113A-N2; 8-port 1U SAS3 12Gbps Hybrid backplane, support up to 6x 2.5-inch SAS3/SATA3 HDD/SSD and 2x SAS3/SATA3/NVMe Storage Devices; Cable 1; CBL-SAST-0631; MINI SAS HD-4 SATA,6G,INT,RF,Cross Over,55CM,55CM SB,30AWG; MCP-260-00111-0N; 1U I/O Shield for X11DPL-i with EMI Gasket; Air Shroud; MCP-310-19015-0N; SC813M,SC113M, DP X9DRL-EF/ X9DRL-7F/ X10DRL-i, X9/X10 mylar air shroud, 12; Manual; MNL-2012-QRG; 1029P-MT/MTR Quick Reference Guide; Riser Card; RSC-RR1U-E8; RSC-RR1U-E8; Heatsink / Retention; SNK-P0067PD; 1U Passive Proprietary CPU Heat Sink for X11DPL Motherboard Equipped with a Square Retention Mechanism; * Power Supply; PWS-605P-1H; 1U 600W Multi Output Power Supply PMbus; * Cable 2; CBL-0160L; NEMA5-15P to C13 US power cord 16AWG 6ft, PBF (default for high watt); * Cable 3; CBL-0335L; CBL,FRONT CNTL,20 TO 20 PIN,RA,RND TUBE,73CM,28AWG; * FAN 1; FAN-0154L4; 40x40x28 mm, 22.5K RPM, SC813MF Middle Cooling Fan,RoHS/REACH; * Front Panel; FPB-FP112; Front control board for SC113,113M (U/C share; * Drive Tray(s); MCP-220-00047-0B; Black gen 3rd hot-swap 2.5inch HDD tray; * Rear Window; MCP-240-00085-0N; STD rear window for SC113 single PWS; * Parts; MCP-260-00078-0N; 1U I/O shield for X10 and X9 Server MB with 5X5mm vent hole and EMI Gasket,RoHS/REACH,PBF; * Peripheral Drive 1; MCP-290-00036-0B; Black DVD dummy tray support 1x2.5 HDD for SC113,815,825,836; * Parts; MCP-290-00037-0N; SC113 Control panel module (w/o DVD); * Rail Set; MCP-290-00102-0N; Outer rail, quick-release type, 25.6\" to 33.05\"; * Rail Set; MCP-290-00107-0N; Inner rail, front, short, screw type; * Rail Set; MCP-290-00110-0N; Inner rail, extension (quick) for 1U 17.2; * Fan Holder; MCP-320-00031-0B; Fan tray for six 40x28 fans(SC813M/113M); * Parts; MCP-340-00001-01; Dummy fan 40x28mm; Part Number; Description; Motherboard / Chassis; MBD-X11DPL-i CSE-113MFAC2-605CB; Super X11DPL-i Motherboard 1U Chassis; Backplane; BPN-SAS3-113A-N2; 8-port 1U SAS3 12Gbps Hybrid backplane, support up to 6x 2.5-inch SAS3/SATA3 HDD/SSD and 2x SAS3/SATA3/NVMe Storage Devices; Cable 1; CBL-SAST-0631; MINI SAS HD-4 SATA,6G,INT,RF,Cross Over,55CM,55CM SB,30AWG; MCP-260-00111-0N; 1U I/O Shield for X11DPL-i with EMI Gasket; Air Shroud; MCP-310-19015-0N; SC813M,SC113M, DP X9DRL-EF/ X9DRL-7F/ X10DRL-i, X9/X10 mylar air shroud, 12; Manual; MNL-2012-QRG; 1029P-MT/MTR Quick Reference Guide; Riser Card; RSC-RR1U-E8; RSC-RR1U-E8; Heatsink / Retention; SNK-P0067PD; 1U Passive Proprietary CPU Heat Sink for X11DPL Motherboard Equipped with a Square Retention Mechanism; * Power Supply; PWS-605P-1H; 1U 600W Multi Output Power Supply PMbus; * Cable 2; CBL-0160L; NEMA5-15P to C13 US power cord 16AWG 6ft, PBF (default for high watt); * Cable 3; CBL-0335L; CBL,FRONT CNTL,20 TO 20 PIN,RA,RND TUBE,73CM,28AWG; * FAN 1; FAN-0154L4; 40x40x28 mm, 22.5K RPM, SC813MF Middle Cooling Fan,RoHS/REACH; * Front Panel; FPB-FP112; Front control board for SC113,113M (U/C share; * Drive Tray(s); MCP-220-00047-0B; Black gen 3rd hot-swap 2.5inch HDD tray; * Rear Window; MCP-240-00085-0N; STD rear window for SC113 single PWS; * Parts; MCP-260-00078-0N; 1U I/O shield for X10 and X9 Server MB with 5X5mm vent hole and EMI Gasket,RoHS/REACH,PBF; * Peripheral Drive 1; MCP-290-00036-0B; Black DVD dummy tray support 1x2.5 HDD for SC113,815,825,836; * Parts; MCP-290-00037-0N; SC113 Control panel module (w/o DVD); * Rail Set; MCP-290-00102-0N; Outer rail, quick-release type, 25.6\" to 33.05\"; * Rail Set; MCP-290-00107-0N; Inner rail, front, short, screw type; * Rail Set; MCP-290-00110-0N; Inner rail, extension (quick) for 1U 17.2; * Fan Holder; MCP-320-00031-0B; Fan tray for six 40x28 fans(SC813M/113M); * Parts; MCP-340-00001-01; Dummy fan 40x28mm; Part Number; Description; Motherboard / Chassis; MBD-X11DPL-i CSE-113MFAC2-605CB; Super X11DPL-i Motherboard 1U Chassis; Backplane; BPN-SAS3-113A-N2; 8-port 1U SAS3 12Gbps Hybrid backplane, support up to 6x 2.5-inch SAS3/SATA3 HDD/SSD and 2x SAS3/SATA3/NVMe Storage Devices; Cable 1; CBL-SAST-0631; MINI SAS HD-4 SATA,6G,INT,RF,Cross Over,55CM,55CM SB,30AWG; MCP-260-00111-0N; 1U I/O Shield for X11DPL-i with EMI Gasket; Air Shroud; MCP-310-19015-0N; SC813M,SC113M, DP X9DRL-EF/ X9DRL-7F/ X10DRL-i, X9/X10 mylar air shroud, 12; Manual; MNL-2012-QRG; 1029P-MT/MTR Quick Reference Guide; Riser Card; RSC-RR1U-E8; RSC-RR1U-E8; Heatsink / Retention; SNK-P0067PD; 1U Passive Proprietary CPU Heat Sink for X11DPL Motherboard Equipped with a Square Retention Mechanism; * Power Supply; PWS-605P-1H; 1U 600W Multi Output Power Supply PMbus; * Cable 2; CBL-0160L; NEMA5-15P to C13 US power cord 16AWG 6ft, PBF (default for high watt); * Cable 3; CBL-0335L; CBL,FRONT CNTL,20 TO 20 PIN,RA,RND TUBE,73CM,28AWG; * FAN 1; FAN-0154L4; 40x40x28 mm, 22.5K RPM, SC813MF Middle Cooling Fan,RoHS/REACH; * Front Panel; FPB-FP112; Front control board for SC113,113M (U/C share; * Drive Tray(s); MCP-220-00047-0B; Black gen 3rd hot-swap 2.5inch HDD tray; * Rear Window; MCP-240-00085-0N; STD rear window for SC113 single PWS; * Parts; MCP-260-00078-0N; 1U I/O shield for X10 and X9 Server MB with 5X5mm vent hole and EMI Gasket,RoHS/REACH,PBF; * Peripheral Drive 1; MCP-290-00036-0B; Black DVD dummy tray support 1x2.5 HDD for SC113,815,825,836; * Parts; MCP-290-00037-0N; SC113 Control panel module (w/o DVD); * Rail Set; MCP-290-00102-0N; Outer rail, quick-release type, 25.6\" to 33.05\"; * Rail Set; MCP-290-00107-0N; Inner rail, front, short, screw type; * Rail Set; MCP-290-00110-0N; Inner rail, extension (quick) for 1U 17.2; * Fan Holder; MCP-320-00031-0B; Fan tray for six 40x28 fans(SC813M/113M); * Parts; MCP-340-00001-01; Dummy fan 40x28mm; Part Number; Description; Motherboard / Chassis; MBD-X11DPL-i CSE-113MFAC2-605CB; Super X11DPL-i Motherboard 1U Chassis; Backplane; BPN-SAS3-113A-N2; 8-port 1U SAS3 12Gbps Hybrid backplane, support up to 6x 2.5-inch SAS3/SATA3 HDD/SSD and 2x SAS3/SATA3/NVMe Storage Devices; Cable 1; CBL-SAST-0631; MINI SAS HD-4 SATA,6G,INT,RF,Cross Over,55CM,55CM SB,30AWG; MCP-260-00111-0N; 1U I/O Shield for X11DPL-i with EMI Gasket; Air Shroud; MCP-310-19015-0N; SC813M,SC113M, DP X9DRL-EF/ X9DRL-7F/ X10DRL-i, X9/X10 mylar air shroud, 12; Manual; MNL-2012-QRG; 1029P-MT/MTR Quick Reference Guide; Riser Card; RSC-RR1U-E8; RSC-RR1U-E8; Heatsink / Retention; SNK-P0067PD; 1U Passive Proprietary CPU Heat Sink for X11DPL Motherboard Equipped with a Square Retention Mechanism; * Power Supply; PWS-605P-1H; 1U 600W Multi Output Power Supply PMbus; * Cable 2; CBL-0160L; NEMA5-15P to C13 US power cord 16AWG 6ft, PBF (default for high watt); * Cable 3; CBL-0335L; CBL,FRONT CNTL,20 TO 20 PIN,RA,RND TUBE,73CM,28AWG; * FAN 1; FAN-0154L4; 40x40x28 mm, 22.5K RPM, SC813MF Middle Cooling Fan,RoHS/REACH; * Front Panel; FPB-FP112; Front control board for SC113,113M (U/C share; * Drive Tray(s); MCP-220-00047-0B; Black gen 3rd hot-swap 2.5inch HDD tray; * Rear Window; MCP-240-00085-0N; STD rear window for SC113 single PWS; * Parts; MCP-260-00078-0N; 1U I/O shield for X10 and X9 Server MB with 5X5mm vent hole and EMI Gasket,RoHS/REACH,PBF; * Peripheral Drive 1; MCP-290-00036-0B; Black DVD dummy tray support 1x2.5 HDD for SC113,815,825,836; * Parts; MCP-290-00037-0N; SC113 Control panel module (w/o DVD); * Rail Set; MCP-290-00102-0N; Outer rail, quick-release type, 25.6\" to 33.05\"; * Rail Set; MCP-290-00107-0N; Inner rail, front, short, screw type; * Rail Set; MCP-290-00110-0N; Inner rail, extension (quick) for 1U 17.2; * Fan Holder; MCP-320-00031-0B; Fan tray for six 40x28 fans(SC813M/113M); * Parts; MCP-340-00001-01; Dummy fan 40x28mm |
| Optional Parts List | Part Number; Description; NVMe AOC card; AOC-SLG3-2E4T; 2 Port NVMe PCI-E x8 Redriver Card; Cable Management Arm; MCP-290-00152-0N; 1U Supermicro Cable Management Arm 2nd Gen; CBL-SAST-0929 CBL-SAST-0531; OcuLink v 1.0 source to MiniSAS HD,INT,PCIe, 57CM,34AWG MINI SAS HD,12G,INT,80CM,30AWG; Storage Controller Card(s) & Cables(s); AOC-S3108L-H8IR-16DD + 2x CBL-SAST-0531 + 1x FAN-0154L4; 8 internal ports, 12Gb/s per port- Gen3, 16HDD, RAID 0, 1, 5, 6, 10, 50, 60; Internal Mini-SAS HD to Mini-SAS HD 80cm,30AWG,12Gb/s; Network Card(s); AOC-SGP-i2 AOC-SGP-i4 AOC-SG-i2 AOC-SG-i4 AOC-STG-b4S AOC-STGN-i2S AOC-STGN-i1S AOC-STG-i2T AOC-STG-i2; - - - - - - - - -; Standard LP, 2x GbE RJ45, PCI-E x4, Intel® i350AM2 Standard LP, 4x GbE RJ45, PCI-E x4, Intel® i350 Standard LP, 2x GbE RJ45, PCI-E x4, Intel® 82575EB Standard LP, 4x GbE RJ45, PCI-E x8, Intel® 82576EB Standard LP, 4x 10GbE SFP+, PCI-E x8, Broadcom® BCM57840S Standard LP, 2x 10GbE SFP+, PCI-E x8, Intel® 82599ES Standard LP, 1x 10GbE SFP+, PCI-E x8, Intel® 82599ES Standard LP, 2x 10GbE RJ45, PCI-E x8, Intel® X540 Standard LP, 2x 10GbE CX4, PCI-E x8, Intel® 82598EB; DVD-ROM / DVD-RW; DVM-PNSC-DVD-SBT3 DVM-TEAC-DVD-SBT5 DVM-PLDS-DVDRW-SBT4 DVM-TEAC-DVDRW-SBT5; - - - -; BLACK PANASONIC SLIM DVD ROM SATA DRIVE BLACK TEAC SLIM DVD ROM SATA DRIVE PHILIPS SLIM BLACK DVD-RW SATA DRIVE BLACK TEAC SLIM DVD-RW SATA DRIVE; DVD-ROM Accessory; MCP-220-81502-0N; Slim SATA DVD kit for SC213,219,813,815,818,819,825,828,829,836,842; TPM 2.0; AOM-TPM-9670V; SPI capable TPM 2.0 with Infineon 9670 controller with vertical form factor; Global Services & Support; OS4HR3/2/1 OSNBD3/2/1; 3/2/1-year onsite 24x7x4 service 3/2/1-year onsite NBD service; Software; SFT-OOB-LIC •; OOB Management Package (per node license); Software; SFT-DCMS-Single; DataCenter Management Package (per node license); Part Number; Description; NVMe AOC card; AOC-SLG3-2E4T; 2 Port NVMe PCI-E x8 Redriver Card; Cable Management Arm; MCP-290-00152-0N; 1U Supermicro Cable Management Arm 2nd Gen; CBL-SAST-0929 CBL-SAST-0531; OcuLink v 1.0 source to MiniSAS HD,INT,PCIe, 57CM,34AWG MINI SAS HD,12G,INT,80CM,30AWG; Storage Controller Card(s) & Cables(s); AOC-S3108L-H8IR-16DD + 2x CBL-SAST-0531 + 1x FAN-0154L4; 8 internal ports, 12Gb/s per port- Gen3, 16HDD, RAID 0, 1, 5, 6, 10, 50, 60; Internal Mini-SAS HD to Mini-SAS HD 80cm,30AWG,12Gb/s; Network Card(s); AOC-SGP-i2 AOC-SGP-i4 AOC-SG-i2 AOC-SG-i4 AOC-STG-b4S AOC-STGN-i2S AOC-STGN-i1S AOC-STG-i2T AOC-STG-i2; - - - - - - - - -; Standard LP, 2x GbE RJ45, PCI-E x4, Intel® i350AM2 Standard LP, 4x GbE RJ45, PCI-E x4, Intel® i350 Standard LP, 2x GbE RJ45, PCI-E x4, Intel® 82575EB Standard LP, 4x GbE RJ45, PCI-E x8, Intel® 82576EB Standard LP, 4x 10GbE SFP+, PCI-E x8, Broadcom® BCM57840S Standard LP, 2x 10GbE SFP+, PCI-E x8, Intel® 82599ES Standard LP, 1x 10GbE SFP+, PCI-E x8, Intel® 82599ES Standard LP, 2x 10GbE RJ45, PCI-E x8, Intel® X540 Standard LP, 2x 10GbE CX4, PCI-E x8, Intel® 82598EB; DVD-ROM / DVD-RW; DVM-PNSC-DVD-SBT3 DVM-TEAC-DVD-SBT5 DVM-PLDS-DVDRW-SBT4 DVM-TEAC-DVDRW-SBT5; - - - -; BLACK PANASONIC SLIM DVD ROM SATA DRIVE BLACK TEAC SLIM DVD ROM SATA DRIVE PHILIPS SLIM BLACK DVD-RW SATA DRIVE BLACK TEAC SLIM DVD-RW SATA DRIVE; DVD-ROM Accessory; MCP-220-81502-0N; Slim SATA DVD kit for SC213,219,813,815,818,819,825,828,829,836,842; TPM 2.0; AOM-TPM-9670V; SPI capable TPM 2.0 with Infineon 9670 controller with vertical form factor; Global Services & Support; OS4HR3/2/1 OSNBD3/2/1; 3/2/1-year onsite 24x7x4 service 3/2/1-year onsite NBD service; Software; SFT-OOB-LIC •; OOB Management Package (per node license); Software; SFT-DCMS-Single; DataCenter Management Package (per node license); Part Number; Description; NVMe AOC card; AOC-SLG3-2E4T; 2 Port NVMe PCI-E x8 Redriver Card; Cable Management Arm; MCP-290-00152-0N; 1U Supermicro Cable Management Arm 2nd Gen; CBL-SAST-0929 CBL-SAST-0531; OcuLink v 1.0 source to MiniSAS HD,INT,PCIe, 57CM,34AWG MINI SAS HD,12G,INT,80CM,30AWG; Storage Controller Card(s) & Cables(s); AOC-S3108L-H8IR-16DD + 2x CBL-SAST-0531 + 1x FAN-0154L4; 8 internal ports, 12Gb/s per port- Gen3, 16HDD, RAID 0, 1, 5, 6, 10, 50, 60; Internal Mini-SAS HD to Mini-SAS HD 80cm,30AWG,12Gb/s; Network Card(s); AOC-SGP-i2 AOC-SGP-i4 AOC-SG-i2 AOC-SG-i4 AOC-STG-b4S AOC-STGN-i2S AOC-STGN-i1S AOC-STG-i2T AOC-STG-i2; - - - - - - - - -; Standard LP, 2x GbE RJ45, PCI-E x4, Intel® i350AM2 Standard LP, 4x GbE RJ45, PCI-E x4, Intel® i350 Standard LP, 2x GbE RJ45, PCI-E x4, Intel® 82575EB Standard LP, 4x GbE RJ45, PCI-E x8, Intel® 82576EB Standard LP, 4x 10GbE SFP+, PCI-E x8, Broadcom® BCM57840S Standard LP, 2x 10GbE SFP+, PCI-E x8, Intel® 82599ES Standard LP, 1x 10GbE SFP+, PCI-E x8, Intel® 82599ES Standard LP, 2x 10GbE RJ45, PCI-E x8, Intel® X540 Standard LP, 2x 10GbE CX4, PCI-E x8, Intel® 82598EB; DVD-ROM / DVD-RW; DVM-PNSC-DVD-SBT3 DVM-TEAC-DVD-SBT5 DVM-PLDS-DVDRW-SBT4 DVM-TEAC-DVDRW-SBT5; - - - -; BLACK PANASONIC SLIM DVD ROM SATA DRIVE BLACK TEAC SLIM DVD ROM SATA DRIVE PHILIPS SLIM BLACK DVD-RW SATA DRIVE BLACK TEAC SLIM DVD-RW SATA DRIVE; DVD-ROM Accessory; MCP-220-81502-0N; Slim SATA DVD kit for SC213,219,813,815,818,819,825,828,829,836,842; TPM 2.0; AOM-TPM-9670V; SPI capable TPM 2.0 with Infineon 9670 controller with vertical form factor; Global Services & Support; OS4HR3/2/1 OSNBD3/2/1; 3/2/1-year onsite 24x7x4 service 3/2/1-year onsite NBD service; Software; SFT-OOB-LIC •; OOB Management Package (per node license); Software; SFT-DCMS-Single; DataCenter Management Package (per node license); Part Number; Description; NVMe AOC card; AOC-SLG3-2E4T; 2 Port NVMe PCI-E x8 Redriver Card; Cable Management Arm; MCP-290-00152-0N; 1U Supermicro Cable Management Arm 2nd Gen; CBL-SAST-0929 CBL-SAST-0531; OcuLink v 1.0 source to MiniSAS HD,INT,PCIe, 57CM,34AWG MINI SAS HD,12G,INT,80CM,30AWG; Storage Controller Card(s) & Cables(s); AOC-S3108L-H8IR-16DD + 2x CBL-SAST-0531 + 1x FAN-0154L4; 8 internal ports, 12Gb/s per port- Gen3, 16HDD, RAID 0, 1, 5, 6, 10, 50, 60; Internal Mini-SAS HD to Mini-SAS HD 80cm,30AWG,12Gb/s; Network Card(s); AOC-SGP-i2 AOC-SGP-i4 AOC-SG-i2 AOC-SG-i4 AOC-STG-b4S AOC-STGN-i2S AOC-STGN-i1S AOC-STG-i2T AOC-STG-i2; - - - - - - - - -; Standard LP, 2x GbE RJ45, PCI-E x4, Intel® i350AM2 Standard LP, 4x GbE RJ45, PCI-E x4, Intel® i350 Standard LP, 2x GbE RJ45, PCI-E x4, Intel® 82575EB Standard LP, 4x GbE RJ45, PCI-E x8, Intel® 82576EB Standard LP, 4x 10GbE SFP+, PCI-E x8, Broadcom® BCM57840S Standard LP, 2x 10GbE SFP+, PCI-E x8, Intel® 82599ES Standard LP, 1x 10GbE SFP+, PCI-E x8, Intel® 82599ES Standard LP, 2x 10GbE RJ45, PCI-E x8, Intel® X540 Standard LP, 2x 10GbE CX4, PCI-E x8, Intel® 82598EB; DVD-ROM / DVD-RW; DVM-PNSC-DVD-SBT3 DVM-TEAC-DVD-SBT5 DVM-PLDS-DVDRW-SBT4 DVM-TEAC-DVDRW-SBT5; - - - -; BLACK PANASONIC SLIM DVD ROM SATA DRIVE BLACK TEAC SLIM DVD ROM SATA DRIVE PHILIPS SLIM BLACK DVD-RW SATA DRIVE BLACK TEAC SLIM DVD-RW SATA DRIVE; DVD-ROM Accessory; MCP-220-81502-0N; Slim SATA DVD kit for SC213,219,813,815,818,819,825,828,829,836,842; TPM 2.0; AOM-TPM-9670V; SPI capable TPM 2.0 with Infineon 9670 controller with vertical form factor; Global Services & Support; OS4HR3/2/1 OSNBD3/2/1; 3/2/1-year onsite 24x7x4 service 3/2/1-year onsite NBD service; Software; SFT-OOB-LIC •; OOB Management Package (per node license); Software; SFT-DCMS-Single; DataCenter Management Package (per node license) |
| Management - Software | Intel® Node Manager IPMI 2.0 KVM with dedicated LAN NMI SSM , SPM , SUM SuperDoctor® 5 Watch Dog |
| Management - Power Configurations | ACPI / APM Power Management |
| Power Supply - AC Input | 100-240V, 50-60Hz |
| Input Output - DOM | 2 Super DOM (Disk on Module) ports |
| PC Health Monitoring - CPU | Monitors for CPU Cores, Chipset Voltages, Memory. 4+1 Phase-switching voltage regulator |
| Power Supply - DC Output | +3.3V: 15A +5V: 18A +5V standby: 3A +12V: 49A -12V: 0.5A |
| Processor - Cores | Up to 28 Cores |
| System Memory - Note | † 2933MHz in two DIMMs per channel can be achieved by using memory purchased from Supermicro |
| Operating Environment - RoHS | RoHS Compliant |
| Operating Environment - Environmental Spec | Operating Temperature: 10°C ~ 35°C (50°F ~ 95°F) Non-operating Temperature: -40°C to 60°C (-40°F to 140°F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing) |
| Product SKUs - SYS-1029P-MT | SuperServer 1029P-MT ( Black ) |
